Unfortunately I can't locate the build pics but it's just a PSU and the heat sinked vid amp chip on a perf board.ĭIY is rarely cheaper than buying off the shelf when you calculate in the time value of money and other factors. I used a terrific (but now unfortunately obsolete) video amplifier chip because it had waaaaaay more bandwidth than needed for this application. Of course in stating this I am assuming that your power supply has enough current to satisfy demand and all the other obvious technicalities are well cared for. If the amp has enough bandwidth and your connections are terminated properly jitter won't be a problem.
This is a very simple device to build, because it is merely a buffer/amplifier.
I made my own word clock distributor a few years ago, when I needed to take the single output of my WC generator and distribute it to about 8 locations throughout the studio. It's not going to take luck, just a little skill.
